CAT G3306NA SULLAIR PDH12-G2 Sweet Compressor Package

Contact for Pricing

Listing Details

CategoryCompressorPackage
Listing ID14066
StatusAvailable
# of Units Available1
Deal PreferenceFor Sale
Price TypeTotal
PackageCompressor - Rocky View Yard
CertificationFuelled Certified
Year2004
Make/ManufacturerSAGE
ModelPDH12-G2
ServiceSweet
ConditionUsed
Fuelled Condition Rating
A
Condition A
New/Unused Equipment

Condition B
Ready to go into operation with minor service (tune-up).
Used but has been overhauled.

Condition C
Requires Overhaul but components are present and not damaged/used beyond repair.

Condition D
Requires Overhaul and major components (vessels, engine, instrumentation, piping, panel, etc.) are missing or damaged beyond repair.

Condition E
Scrap or suitable for parts. Major item(s) missing (I.e. Separator Package missing separator vessel or Compressor Package missing driver).
Compressor Package Details
MAWP450 PSI
Compressor Details
Compressor TypeScrew
Driver Details
Driver TypeEngine
Driver Fuel TypeUnknown
Driver Horse Power145 HP
Notes

Description: Unit ID: 100202

CAT Driver Tag*
Serial: N4F01862
Model: G3304NA
AR No: 222-9043
Power: 71 kw
HP: 95
Full Load RPM: 1800

SULLAIR Compressor Tag*
Serial: 200604160079
Model: PDH12-G2
Gear Ratio: 1.78
VI: 3.5

AXH Air Cooler Tag*
Model: 42VI
Job No: 37815E-9271
Tag No: 100206
Ref No: 1768

Cooler Ppressure Tag*
Serial: 92711
MAWP: 14 PSI at 300°F
MDMT: -20°F at 14 PSi
Year: 2004
Hydro: 75 PSIG

Murphy Control Panel Tag*
Model: M02-068
Job No: M02-068-084
Annunciation: 5VDC Non-Incendive
Input Voltage: 150VDC Suitable for Class I, Div. 2, Group C & D

Inlet Scrubber Tag*
W RT2
Serial: 14275-7
CRN: R2203.2
A#: 509051
MAWP: 245 PSI at 250°F
MDMT: -20°F at 245 PSI
Year: 2004
Tag No: V-1
Weight: 575 LBS
Volume: 5.50 FT3
CA: 0.125"
Shell THK: 0.375"
Shell MAT'L: SA-106-B
Head THK: 0.3125"
Head MAT'L: SA-516-70

Oil Separator Tag*
W RT-2
Serial: 14276-5
CRN: R1165.213
A#: 509074
MAWP: 450 PSI at 250°F
MDMT: -20°F at 450 PSi
Year: 2004
Tag No: V-2
Weight: 1250 LBS
Volume: 4.5 FT3
CA: 0.125"
Shell THK: 0.375"
Shell MAT'L: SA-106-B
Head THK: 0.3125"
Head MAT'L: SA-516-70N

Sub Type: Pneumatic TTDJ

Brand: SULLAIR Corporation

Make 3: CAT

Model 3: 3306NA

Serial Number 3: N4F00654

Make 4: AXH Air-Coolers

Model 4: 42 VI

Make 5: Murphy

Frame Serial Number: 200604160079

Rated Rpm 3: 1800

Certified Report

Location
Yard

NEXT Compression - Rocky View Yard

Status
Equipment Still in Operation

No

Does the skid have skirting that needs to be removed

No

Equipment still connected to piping

No

Equipment still welded down to piles

No

Equipment on a gravel pad

No

Electrical still connected to the equipment

Unknown

Have vessels been cleaned out

Unknown

Shiploose items

No

Service
Has equipment been preserved? If so, when?

Unknown

Site Logistics
Equipment accessibility in yard or work site
Access into work site
Any road use agreement to access site

Yes

Vessel Registrations
Provincial Vessel RegistrationsAB, BC, SK
Equipment Appearance
Missing Parts
Corrosion
Animal Infestation
Overall cleanliness of package
